| Model | MW3586-U-YP |
| Panel | |
| Backlight | DLED backlight |
| Panel Size | 86" |
| Resolution | 3840 × 2160 |
| Brightness (cd/m²) | 350 |
| Contrast Ratio | 4000:1 |
| Response Time (ms) | 8 |
| Color Support | 1.07 B |
| Viewing Angle (H/V) | 178°/178° |
| Lifespan (h) | 50000 |
| Refresh rate (Hz) | 60 |
| Color Gamut | 72% NTSC |
| Surface Hardness | 9H (7 on the Mohs scale) |
| Haze Value | 25% |
| Display Size (mm) | 1895 x 1065.9 |
| Pixel Pitch (H × V) (mm) | 0.49 x 0.49 |
| Touch | |
| Touch Control | Up to 40-point multi-touch (WIN: 40-point, Android: 32-point) |
| Touch Precision (mm) | 2 |
| Touch Response Time (ms) | ≤5 |
| Touch technology | Infrared touch |
| System | |
| CPU | 8 × A55 |
| RAM | 8 GB |
| ROM | 128 GB |
| CPU Frequency | 1.2GHz |
| Operation System | Android 14.0 |
| Interface | |
| Video Input | 2 x HDMI IN 1 x VGA |
| Video Output | 1 x HDMI OUT |
| Audio Input | 1 x 3.5mm interface |
| Audio Output | 1 x COAX, 1 x 3.5mm interface |
| Other Interfaces | 1 x RS232, 4 x USB 2.0, 1 x USB 3.0, 1 x USB Type-C, 2 x TOUCH OUT, 1 x TF CARD |
| Network | 1 x RJ45 |
| Audio | |
| Speaker | 2 x 15W |
