| Model | MW7715-MIS-H1 |
| Module | |
| Pixel Pitch | P1.5 |
| Module Resolution (W × H) | 208 × 104 |
| Module Dimensions (mm) | 320 × 160 × 7.5 |
| Signal Source Interface | HUB75 |
| Processing Image | |
| Single Pixel Brightness Correction | Support |
| Single Pixel Color Correction | Support |
| Brightness (nits) | 600 |
| Color Temperature (K) | 2000 to 12000 adjustable |
| Viewing Angle (H/V) | 160°/140° |
| Center Distance Deviation of LED | < 3% |
| Brightness Uniformity | ≥ 95% |
| Color Uniformity (Cx, Cy) | ±0.003 |
| Contrast Ratio | 3000: 1 |
| Processing performance | |
| Pixel Density (pitch/m²) | 422500 |
| Surface Evenness (mm) | ≤ 0.2 |
| Grayscale (bit) | 14 |
| Scanning Mode (S) | 52 |
| Drive Mode | Constant current driving |
| Refresh Rate (Hz) | 3840 |
| Electrical | |
| Power Supply | DC 4.5 V |
| Average Power Consumption (W) | 150 |
| Max. Power Consumption (W/m²) | 450 |
| General | |
| Curvature | ≥ 150° |
| Ingress Protection | IP30 |
| Weight (kg/pcs) | 0.3 |
| Operating Temperature | -10°C to 40°C |
| Operating Humidity | 10% to 80% RH, non-condensing |
| Storage Temperature | -20°C to 50°C |
| Storage Humidity | 10% to 60% RH, non-condensing |
| LED Lifetime (h) | 50000 |
